Sink Universal VSTR50DKX

Product Family

Sink

Aesthetics

Universal

Sink type

Single-pressed bowl

Building in type

Undermount

No. of bowls

1

Local stockists

Compare

Highlights
Features
Accessories
Download

PVD SINKS

PVD SINKS

The PVD (Physical Vapour Desposition) process creates stunning finishes, which are durable and highly resistant to wear and abrasion.

The base of the sink is made of high quality 18/10 stainless steel with a PVD coating, which is available in copper, gun metal and brass.

Type

Product Family: Sink

Sink type: Single-pressed bowl

Sink material: Stainless steel

Sink dimensions: 50 cm

No. of bowls: 1

EAN code: 8017709276812

Aesthetics

Under table top installation: The sink is fixed under tabletop, which extends the work surface and the depth of the sink.

Colour: Black

Finishing: PVD Brushed

Aesthetics: Universal

Series: Mira

Type of steel: AISI304

Tap hole / precut tap hole: No Taphole

Building in type: Undermount

Technical Features

Coating thickness between 0.2mm and 2mm

The manufacturing process of PVD treatment is 100% green and eco-friendly

PVD coatings are hypoallergenic and suitable for use in contact with food

Cupboard width required for sink installation

Width (mm): 542 mm

Cutout dimension undermount (mm): 404*504 mm

Tap hole diameter: 35 mm

No. of clips: 8

Type of clips: Undermount clip

Characteristics of PVD coating: Coating thickness , Eco-friendly, Pre-assembled gasket, Hypoallergenic

Base unit size: 60 cm

Bowl

Sink depth - depending on the model, the depth can be from13 to 24,5

Bowl type: Minimum radius

Bowl dimensions, WxDxH (mm): 500 x 400 x 200 mm

Bowl thickness (mm): 1 mm

Bowl depth (mm): 200 mm

Radius corner bowl: 15 mm

Overflow: Yes, flush fitted

Strainer position: Wall position

Strainer dimension: 3.5"

Logistic Information

Dimensions of the product WxDxH (mm): 200x542x442 mm

Net weight (kg): 4.500 kg

Gross weight (kg): 6.970 kg

Depth (mm): 442 mm

Product Height (mm): 200 mm

Packed width: 640 mm

Packaged depth: 540 mm

Height (mm) packed: 290 mm

Dimensions of the packed product (mm): 290X640X540 mm

Maximum stackability: 7

Type of packaging: Cardboard

Packaging composition - paper & cardboard (kg): 2.820 kg

Packaging composition - polystyrene (kg): 0.000 kg

Packaging composition - wood (kg): 0.000 kg

Packaging composition - plastic (kg): 0.020 kg

Accessories Included

Accessories for installation: Strainer, Siphon with dishwasher outlet connection, Fixing clips

Optional

KITFD050UK

Accessories, Type: Waste disposal, Sinks

Technical drawing

Download (png)

Instruction manual

User manual (ALL) (pdf)

Product sheet

Download

Brochure

Download

3D file

Download
