Whilst stocks last

Classic Chimney Cooker Hood, Black

KD100HNE

Name: Classic Chimney Cooker Hood, Black KD100HNE
Brand: Smeg
SKU: KD100HNE

Energy consumption Dimensions

Shop online

Local stockists

Compare

Product code: KD100HNE

Wall hood, 100 cm, with an important and sophisticated design, made to be the protagonist of the kitchen, combining powerful suction and silent operation

Highlights
Features
Accessories
Download

Timeless design

With its strict design form, the simple classic aesthetic is timeless - fitting into a contemporary or traditional kitchen setting with ease. The range is made up of a series co-ordinating appliances finished in smart stainless steel with matching controls and handles. The collection comprises ovens, coffee machines, hobs, extractor hoods, dishwashers and wine coolers.

OPERA AESTHETIC

Modern in design thanks to its clean and elegant styling, ergonomic lever shaped controls and robust handles, Opera is a truly aspirational range for serious cooks. Crafted with real attention to detail and using 18/10 Stainless Steel, the range is robust and built to last.

Opera hoods are available in widths ranging from 90cm - 150cm.

Ducting or re-circulating

Most Smeg hoods offer the choice of ducting or re-circulating, so you can choose your preferred method.

Venting/ducting out provides optimum extraction of cooking fumes by expelling them outside, using a vent kit (available as an optional accessory)
This hood has 150mm vent outlet, so you can choose between the following options:

SP150 - Simple vent kit for hoods with a 150mm diameter vent outlet
SP150FLAT - Comprehensive vent kit for hoods with a 150mm diameter vent outlet

Re-circulating extracts the cooking fumes and passes them through active charcoal filters (available as an optional accessory), recirculating the cleaned air back into the room. To find out which charcoal filter your hood needs, see the accessory tab on the hoods specification.

Dishwasher safe

Some models have grease filters which can be easily removed from the hood and cleaned in the dishwasher, so no manual hand washing is required.

Intensive extraction

A powerful intensive speed can be selected when quick extraction is needed, whether you’re creating a sizzling stir fry or a preparing an aromatic curry, even the strongest cooking odours will be removed in no time.

LED LIGHTING

These lights are long lasting, save money and perfectly illuminate the work surface below. They can be switched on regardless of the fans, and used simply to create ambience lighting in the kitchen.

STAINLESS STEEL FILTERS

Easy cleaning with washable stainless steel metal grease filter(s) which can be put into the dishwasher.

Aesthetics

Aesthetics: Classic

Colour: Black

Design: Chimney

Finishing: Gloss Black

Material: Painted material

Type of steel: Polished

Program / Functions

No. of speeds: 3

Intensive speed: Yes

Type

Product family: Hood

Hood Type: Chimney Cooker Hoods

Hood width: 100 cm

Extraction: Ducted out or re-circulation possible

EAN code: 8017709276881

Technical Features

No. of lights: 2

Light type: LED

Light power: 1 W

Light colour temperature scale (K): 4000 K

Free outlet maximum capacity: 830 m³/h

Motor power: 275 W

No. of filters: 3

Anti-grease filters: Stainless steel

Minimum distance from GAS hob: 750 mm

Minimum distance from ELECTRIC hob: 650 mm

Vent outlet: 150 mm

Non return valve: Yes

Controls

Control setting: Control knobs

Control knobs: Classic

No. of controls: 2

Controls colour: Steel effect

Performance / Energy Label

Energy efficiency class ( EEC): A+

Fluid Dynamic Efficiency class (FDEC): A

Grease Filtering Efficiency Class (GFEC): D

Lighting Efficiency Class (LEC): A

Annual Efficiency Consumption (AEChood): 39 kWh/year

Fluid Dynamic Efficiency (FDE): 35.9

Lighting Efficiency (LE): 75.5 lux/W

Grease Filtering Efficiency (GFE): 71.5 %

Air flow at minumum speed (Qmin): 297 m³/h

Maximum extraction rate: 639 m³/h

Intensive extraction rate: 792 m³/h

Airbourne acouistical A-weighted sound Power Emission at minimum speed (SPEmin): 49 dBA

Airborne acoustical A-weighted sound Power Emission at maximum speed (SPEmax): 68 dBA

Airbourne acoustical A-weighted sound power emission at boost speed (SPEboost): 72 dBA

Time increase factor (F): 0.7

Energy Efficiency Index per first cavity: 40

Measured air flow rate at best efficiency point (Qbep): 394 m³/h

Measured air pressure at best efficiency point (Qbep): 483 Pa

Measured electric power input at best efficiency point (Wbep): 147 W

Normal Power of the light system (Wl): 2 W

Average illumination of the light on the cooking surface (Emiddle): 166 lux

Sound power level at highest setting (Lwa): 68 dBA

Electrical Connection

Nominal power: 277 W

Voltage: 220-240 V

Frequency (Hz): 50-60 Hz

Plug: No

Power supply cable length: 1500 mm

Speed 1

Extraction rate IEC 61591: 297 m³/h

Noise level IEC 60704-2-13: 49 dBA

Power: 160 W

Speed 2

Extraction rate IEC 61591: 431 m³/h

Noise level IEC 60704-2-13: 58 dBA

Power: 213 W

Speed 3

Extraction rate IEC 61591: 639 m³/h

Noise level IEC 60704-2-13: 67 dBA

Power: 240 W

Intensive speed

Extraction rate (IEC 61591): 792 m³/h

Noise level IEC 60704-2-13: 72 dBA

Power: 272 W

Logistic Information

Dimensions of the product HxWxD (mm): 800x1000x540

Width: 1000 mm

Depth (mm): 540 mm

Product Height (mm): 800 mm

Net weight (kg): 17.460 kg

Gross weight (kg): 21.800 kg

Packed width: 1070 mm

Packaged depth: 510 mm

Height (mm) packed: 680 mm

Dimensions of the packed product (mm): 680x1070x510

Maximum stackability: 4

Type of packaging: Cardboard

Packaging composition - paper & cardboard (kg): 3.116 kg

Packaging composition - polystyrene (kg): 0.800 kg

Packaging composition - wood (kg): 0.300 kg

Packaging composition - plastic (kg): 0.087 kg

Optional

Accessories, Type: Charcoal filter, Hoods

Accessories, Type: Charcoal filter, Hoods
