100 cm Chimney Cooker Hood - Black Choice of Recirculating or Ducted Extraction Design: Classic KD100HNE

Product family
Hood
Hood Type
Chimney Cooker Hoods
Aesthetics
Classic
Colour
Black
Hood width
100 cm
Energy efficiency class ( EEC)
A+
  • Highlights
  • Features
  • Accessories
  • Download

Timeless design

With its strict design form, the simple classic aesthetic is timeless - fitting into a contemporary or traditional kitchen setting with ease. The range is made up of a series co-ordinating appliances finished in smart stainless steel with matching controls and handles. The collection comprises ovens, coffee machines, hobs, extractor hoods, dishwashers and wine coolers.

OPERA AESTHETIC

Modern in design thanks to its clean and elegant styling, ergonomic lever shaped controls and robust handles, Opera is a truly aspirational range for serious cooks. Crafted with real attention to detail and using 18/10 Stainless Steel, the range is robust and built to last.

Opera hoods are available in widths ranging from 90cm - 150cm.

Ducting or re-circulating

Most Smeg hoods offer the choice of ducting or re-circulating, so you can choose your preferred method.

  • Venting/ducting out provides optimum extraction of cooking fumes by expelling them outside, using a vent kit (available as an optional accessory)
    This hood has 150mm vent outlet, so you can choose between the following options:

SP150 - Simple vent kit for hoods with a 150mm diameter vent outlet
SP150FLAT - Comprehensive vent kit for hoods with a 150mm diameter vent outlet

  • Re-circulating extracts the cooking fumes and passes them through active charcoal filters (available as an optional accessory), recirculating the cleaned air back into the room. To find out which charcoal filter your hood needs, see the accessory tab on the hoods specification.

Dishwasher safe

Some models have grease filters which can be easily removed from the hood and cleaned in the dishwasher, so no manual hand washing is required.

Intensive extraction

A powerful intensive speed can be selected when quick extraction is needed, whether you’re creating a sizzling stir fry or a preparing an aromatic curry, even the strongest cooking odours will be removed in no time.

LED LIGHTING

These lights are long lasting, save money and perfectly illuminate the work surface below. They can be switched on regardless of the fans, and used simply to create ambience lighting in the kitchen.

STAINLESS STEEL FILTERS

Easy cleaning with washable stainless steel metal grease filter(s) which can be put into the dishwasher.

Type

Product family: Hood
Hood Type: Chimney Cooker Hoods
Hood width: 100 cm
Extraction: Ducted out or re-circulation possible
EAN code: 8017709276881

Aesthetics

Colour: Black
Finishing: Gloss Black
Aesthetics: Classic
Design: Chimney
Material: Painted material
Type of steel: Polished

Programs / Functions

Intensive/turbo setting: when extra fast extraction is required.
No. of speeds: 3
Intensive speed: Yes

Controls

Control setting: Control knobs
Control knobs: Classic
No. of controls: 2
Controls colour: Steel effect

Technical Features

Filters: Model has filters to help remove grease from the steam emanating from the pans during cooking. Lights: All cooker hoods feature lights to illuminate the cooking area or add to the ambience of the kitchen.
No. of lights: 2
Light type: LED
Light power: 1 W
Light colour temperature scale (°K): 4000 °K
Free outlet maximum capacity: 830 m³/h
Motor power: 275 W
No. of filters: 3
Anti-grease filters: Stainless steel
Minimum distance from GAS hob: 750 mm
Minimum distance from ELECTRIC hob: 650 mm
Vent outlet: 150 mm
Non return valve: Yes

Performance / Energy Label

???Class_Arrows_A+++D_A+???
Energy efficiency class ( EEC): A+
Fluid Dynamic Efficiency class (FDEC): A
Grease Filtering Efficiency Class (GFEC): D
Lighting Efficiency Class (LEC): A
Annual Efficiency Consumption (AEChood): 39 KWh/year
Fluid Dynamic Efficiency (FDE): 35.9
Lighting Efficiency (LE): 75.5 lux/W
Grease Filtering Efficiency (GFE): 71.5 %
Air flow at minumum speed (Qmin): 297 m³/h
Maximum extraction rate: 639 m³/h
Intensive extraction rate: 792 m³/h
Airbourne acouistical A-weighted sound Power Emission at minimum speed (SPEmin): 49 dB(A)
Airborne acoustical A-weighted sound Power Emission at maximum speed (SPEmax): 68 dB(A)
Airbourne acoustical A-weighted sound power emission at boost speed (SPEboost): 72 dB(A)
Time increase factor (F): 0.7
Energy Efficiency Index per first cavity: 40
Measured air flow rate at best efficiency point (Qbep): 394 m³/h
Measured air pressure at best efficiency point (Qbep): 483 Pa
Measured electric power input at best efficiency point (Wbep): 147 W
Normal Power of the light system (Wl): 2 W
Average illumination of the light on the cooking surface (Emiddle): 166 lux
Sound power level at highest setting (Lwa): 68 dB(A)

Electrical Connection

Nominal power: 277 W
Voltage: 220-240 V
Frequency (Hz): 50-60 Hz
Power supply cable length: 1500 mm

Speed 1

Extraction rate IEC 61591: 297 m³/h
Noise level IEC 60704-2-13: 49 dB(A)
Power: 160 W

Speed 2

Extraction rate IEC 61591: 431 m³/h
Noise level IEC 60704-2-13: 58 dB(A)
Power: 213 W

Speed 3

Extraction rate IEC 61591: 639 m³/h
Noise level IEC 60704-2-13: 67 dB(A)
Power: 240 W

Intensive speed

Extraction rate (IEC 61591): 792 m³/h
Noise level IEC 60704-2-13: 72 dB(A)
Power: 272 W

Logistic Information

Dimensions of the product HxWxD (mm): 800x1000x540
Width: 1000 mm
Depth (mm): 540 mm
Product Height (mm): 800 mm
Net weight (kg): 17.460 kg
Gross weight (kg): 21.800 kg
Packed width: 1070 mm
Packaged depth: 510 mm
Height (mm) packed: 680 mm
Dimensions of the packed product (mm): 680X1070X510
Maximum stackability: 4
Type of packaging: Cardboard
Packaging composition - paper & cardboard (kg): 3.116 kg
Packaging composition - polystyrene (kg): 0.800 kg
Packaging composition - wood (kg): 0.300 kg
Packaging composition - plastic (kg): 0.087 kg
