Divina Cucina

Smeg & Dolce&Gabbana

KT90DGC

Product family
Hood
Hood Type
Decorative wall hood
Aesthetics
Victoria
Series
Divina Cucina
Colour
Decorated / Special
Hood width
90 cm
Energy efficicency class ( EEC)
A
Decoration / Special colour
Carretto
  • Highlights
  • Features
  • Accessories
  • Download

Dolce&Gabbana and Smeg continue to join forces to celebrate all things ‘Made in Italy’ alongside the companies shared art and design values. Referencing the colours and beauty of Sicily, this revolutionary collaboration has re-invented the perception of home appliances, no longer merely products, but instead true works of art in the home.

The Divina cucina range plays tribute to Italy’s heritage, traditions and popular festivals in the form of a new freestanding range cooker and hood complete with matching fridge, all characterised by unique bold colours and narrative. This piece is inspired by Sicilian puppet theatre and traditional hand-painted carts, dominated by fiery tones of red and orange.

Ducting or re-circulating

Most Smeg hoods offer the choice of ducting or re-circulating, so you can choose your preferred method.

Ducting out extracts cooking fumes and expels them outside, using a vent kit (available as an optional accessory) The diameter of the ducting hose should match the vent outlet of the hood (which can be found in the features tab)

SP150 - Simple vent kit for hoods with a 150mm diameter vent outlet
SP150FLAT - Comprehensive vent kit for hoods with a 150mm diameter vent outlet
SP215 - Simple vent kit for hoods with a 120mm diameter vent outlet
SP217 - Comprehensive vent kit for hoods with a 120mm diameter vent outlet

Re-circulating extracts the cooking fumes and passes them through active charcoal filters (available as an optional accessory), recirculating the cleaned air back into the room. To find out which charcoal filter your hood needs, check the accessory tab on the hoods specification.

Type

Product family: Hood
Hood Type: Decorative wall hood
Hood width: 90 cm
Extraction: Expulsion
EAN code: 8017709266721

Aesthetics

Colour: Decorated / Special
Decoration / Special colour: Carretto
Finishing: Gloss
Aesthetics: Victoria
Series: Divina Cucina
Collaborations: Smeg & Dolce&Gabbana
Design: Chimney
Material: Painted material
Type of steel: Brushed

Controls

Control setting: Control knobs
Control knobs: Victoria
No. of controls: 2
Controls colour: Steel effect

Programme / Functions

Intensive/turbo setting: when extra fast extraction is required.
No. of speeds: 3
Intensive speed: Yes

Technical Features

Filters: Model has filters to help remove grease from the steam emanating from the pans during cooking. Lights: All cooker hoods feature lights to illuminate the cooking area or add to the ambience of the kitchen.
No. of lights: 2
Light type: LED
Light power: 1 W
Light color temperature scale (°K): 3000 °K
Free outlet maximum capacity: 820 m³/h
Motor power: 275 W
No. of filters: 3
Anti-grease filters: Stainless steel
Minimum distance from GAS hob: 750 mm
Vent outlet: 150 mm
Minimum distance from ELECTRIC hob: 650 mm
Non return valve: Yes

Performance / Energy Label

A: Product drying performance, measured from A+++ to D / G depending on the product family
Energy efficicency class ( EEC): A
Fluid Dynamic Efficiency class (FDEC): A
Grease Filtering Efficiency Class (GFEC): C
Lighting Efficiency Class (LEC): A
Annual Efficiency Consumption (AEChood): 59 kWh/a
Fluid Dynamic Efficiency (FDE): 30
Lighting Efficiency (LE): 102.3 lux/W
Grease Filtering Efficiency (GFE): 76.6 %
Air flow at minumum speed (Qmin): 334 m³/h
Air flow at maximum speed (Qmax): 567 m³/h
Air flow at boost speed (Qboost): 788 m³/h
Airbourne acouistical A-weighted sound Power Emission at minimum speed (SPEmin): 49 dB(A)
Airborne acoustical A-weighted sound Power Emission at maximum speed (SPEmax): 61 dB(A)
Airbourne acoustical A-weighted sound power emission at boost speed (SPEboost): 69 dB(A)
Time increase factor (F): 1.00
Energy Efficiency Index per first cavity: 52.4
Measured air flow rate at best efficiency point (Qbep): 438 m³/h
Measured air pressure at best efficiency point (Qbep): 434 Pa
Measured electric power input at best efficiency point (Wbep): 176 W
Normal Power of the light system (Wl): 2 W
Average illumination of the light on the cooking surface (Emiddle): 225 lux
Sound power level at highest setting (Lwa): 61 dB(A)

Electrical Connection

Nominal power: 278 W
Voltage: 220-240 V
Frequency (Hz): 50-60 Hz

Speed 1

Extraction rate IEC 61591: 334 m³/h
Noise level IEC 60704-2-13: 49 dB(A)
Power: 199 W

Speed 2

Extraction rate IEC 61591: 439 m³/h
Noise level IEC 60704-2-13: 57 dB(A)
Power: 231 W

Speed 3

Extraction rate IEC 61591: 567 m³/h
Noise level IEC 60704-2-13: 61 dB(A)
Power: 260 W

Intensive speed

Extraction rate (IEC 61591): 788 m³/h
Noise level IEC 60704-2-13: 69 dB(A)
Power: 280 W

Logistic Information

Dimensions of the product (mm): 740x895x530
Width: 895 mm
Depth (mm): 530 mm
Product Height (mm): 740 mm
