Washer dryer Universal WDF147X-2

Product Family
Washer dryer
Colour
Stainless steel
Aesthetics
Universal
Energy Efficiency Class (Complete cycle)
E
  • Highlights
  • Features
  • Download

New energy rating

Energy rating bands have recently been re-scaled and revert to a simple A-G scaling, with no plusses.

This product would have been rated B on the previous energy rating scale.

Although re-scaled, this product is still just as energy efficient.



READ THE ARTICLE

Extraordinarily clean

For longer washer-dryer life, Smeg's patented Autoclean system prevents lint and grime buildup by cleaning the ducts from fabric threads. The device automatically signals when to perform cleaning, keeping both the machine and the clothes in top condition.

One less worry

The Acqua Stop system provides peace of mind and safety: it detects anomalies and, in the event of a leak, immediately shuts off the water supply, avoiding flooding and damage to the appliance or home. It reduces water and energy consumption, minimising environmental and economic impact.

Highest performance in the smallest space

Smeg fully integrated washing machines and washer-dryers blend seamlessly into the design of home environments. They allow for easier cleaning, tidiness and space-saving, a great choice for smaller living spaces.
AQUASTOP

A safety features which ensures protection against water leakage.

DELAY TIMER

A delay timer from 1 to 24 hrs can be set to run the programme at a convenient time or to take advantage of off-peak energy periods.

FLEXITIME

The FlexiTime option allows the user to reduce the time of the cycle selected, providing extra flexibility and control.

AUTOMATIC LOAD BALANCING

An unbalanced load can cause damage to the machine, causing noise and vibration. Smeg's machines ensure that laundry is properly distributed in the drum. If unbalanced load is detected, the spin speed is automatically adjusted.

Type

Product Family: Washer dryer
Installation: Free-standing
Load type: Frontal
Max spin speed: 1400 rpm
Commercial width: 60 cm
Commercial depth: Standard capacity
EAN code: 8017709304379

Aesthetics

Colour: Stainless steel
Finishing: Fingerproof
Aesthetics: Universal
Front panel colour: Stainless steel
Led/display colour: Orange
Display frame colour: Silver
Function button colour: Silver
No. of control knobs: 1
Programme/temperature knob colour: Silver
Door colour: Silver
Handle colour: Silver
Top colour: Stainless steel

Programs / Functions

Gentle drying: program designed to get laundry ready for easy ironing.
Controls: Electronic
No. of programmes: 15
Special Clean programme, to remove residual fluff: Yes
Washing Temperature: Cool, 20°C, 30°C, 40°C, 80°C, 90°C
Display: Residual time indicator, delay start, Recommended load indicator, programme status indication
Programme selection knob: Yes
Delay timer option: From 1 to 24 h
Programme progress indicator (light): On display
End of cycle indicator (light): On display
Drying function: Yes
Programmes
  • Eco 40-60
  • Intensive drying
  • Cotton: For soiled fabrics in cotton Cotton
  • Cleaning programme: A cleaning programme has been created to maintain the performance of washer/dryers. The display shows automatically when cleaning is required. Clean
  • Gentle drying: program designed to get laundry ready for easy ironing. Delicate drying
  • Delicate: Clothing such as underwear, hosiery and luxury fabrics should be dried on the delicate cycle to help extend the life of the clothing. Delicates
  • To drain the water in the machine. Drain + Spin
  • Mixed fabrics: this cycle is designed for lightly soiled laundry in a
mix of cottons and synthetics, or can be used just to refresh stored items. Mix
  • Night: an ideal programme for those who want to take advantage of off-peak energy periods, this cycle is particularly quiet due to slower rotations of the drum. Night
  • Super fast 15 min: a programme designed to wash small amounts
of laundry fast, ideal for washing lightly soiled garments. Quick wash 15 min
  • To drain the water into the basket + centrifuge action Rinse + Spin
  • Shirts: a cycle to wash shirts in a short time with the utmost care, using a delicate spin for easy ironing. Shirts
  • Gym: Gym, a cycle designed for washing lightly soiled garments, ie sports wear, this is a fast wash which is also kind to fabrics. Sport
  • Synthetics:  to wash your synthetic clothes (shirts, blouses, synthetic/cotton blends, etc.). It washes with a gentle action and has a shorter washing cycle compared to the Cottons programme. For curtains and tulle, use the Synthetic 40˚C programme with prewash and anti-creasing functions selected. As their meshed texture causes excessive foaming, wash the veils/tulle by putting little amount of detergent into the main wash compartment. Do not put detergent in the prewash compartment. Synthetics
  • Wool: this programme for wool or delicate fabrics uses slower rotations of the drum to ensure the utmost care for clothing. Wool
Buttons/Options
  • Delay timer: can be set to run the programme at a convenient time or to take advantage of off-peak energy periods. Delay timer
  • FlexiTime: The FlexiTime option allows the user to reduce the time of the cycle selected, providing extra flexibility and control. FlexiTime
  • Prewash: program designed for heavily soiled garments. Prewash
  • Extra Rinse: Extra Rinse: adds an extra rinse cycle to that already provided in the program chosen, to remove any residual detergent. This function is particularly suitable for those with allergies or skin problems. Additional rinse
  • Easy Iron: this is an option which can be selected to ensure the
finished laundry is left with less creases to make ironing easier. Anti-wrinkle (easy ironing)
  • Intensive: this option intensifies the selected program. Cycle duration and water consumption are reduced by taking into account the type of laundry, while still guaranteeing excellent washing results, even in the case of stains that are difficult to eliminate. Intensive
  • Gentle drying: program designed to get laundry ready for easy ironing. Drying

Options

Drying option: Yes

Technical Features

This option advises when the periodic cleaning of the filters is needed, in order to avoid forgetfulness and thus guarantee the perfect functioning of the dryer over time. The convenient position of the filters makes maintenance fast and extremely simple. Automatic Load Balancing: provides an ideal distribution of laundry in the drum. In case if the imbalance is detected, the rotation speed starts being controlled in such way to evenly redistribute laundry in the drum, and thus reduce vibration. Total acquastop: Most models of Smeg dishwashers are equipped with Acquastop Totale, which allows to avoid flooding as a result of water leakage. The system consists of a a float sensor, disposed under the inner chamber of a dishwasher, which blocks water supply inside the appliance in case of water leakage into the lower tray. An additional electromagnetic valve on the water inlet hose also automatically blocks water supply if detecting water leakage in the hose.
For Laundry: Total acquastop, the product is built with 3 levels of anti-flood devices to ensure protection against water leakage.
For Laundry: Total acquastop, the product is built with 3 levels of anti-flood devices to ensure protection against water leakage. Child lock: some models are fitted with a device to lock the programme/cycle so it cannot be accidentally changed. Variable load: In all models of washing machines is present the system of variable load, according to which the machine automatically diversifies the wash cycle and the time of operation depending on the quantity and type of laundry introduced, allowing a significant saving of water and
energy power, up to 30% compared to the versions with fixed load. Autocleaning system: Autocleaning system avoids the formation of lint and impurities inside the condensation system ensuring maximum reliability of the machine 30 cm: Large loading hatch of 30-32-33 cm in diameter, makes laundry loading and unloading easier and faster with maximum ease of use. LED display: to show programmes, functions and options selected and the
time to the end of the cycle.
Type of motor: Standard
Display type: LED
Electronic control functioning: Yes
Display/led for temperature regulation: Yes
Spin speed selection on display/LED: No spin/ 600/ 800/ 1000/ 1200/ 1400
Polypropilene tank: Yes
Basket: Stainless steel
Drum capacity: 54 l
Door diameter: 30 cm
Door opening: 180°
Automatic variable load: Yes
Antifoam system: Yes
Load balancing system: Automatic
Easy to access filter: Yes
Child lock (functions block): Control block
Anti-flood system: Yes
Autocleaning system: Yes
Aquastop system: Total
Water supply: Single, cold
Liquid detergent accessory as standard: Yes

Performance / Energy Label NEW

This shows the amount of laundry that can be inserted into the tumble dryer in KG. Drum has maximum capacity of 7kg of dry laundry. Energy efficiency class E
Rated capacity (Washing cycle): 7 kg
Rated capacity (Complete cycle): 4 kg
Energy Efficiency Class (Washing cycle): E
Energy Efficiency Class (Complete cycle): E
Weighted energy consumption [per 100 cycles, (Complete cycle)]: 266 KWh
Weighted energy consumption [per 100 cycles, (Washing cycle)]: 77 KWh
Water consumption (Washing cycle): 44 litre
Water consumption (Complete cycle): 68 litre
Spin-drying efficiency class: B
Programme duration at rated capacity: 2:50 h:min
Programme duration at rated capacity: 5:30 h:min
Airborne acoustical noise emission class (spinning phase): B
Airborne acoustical noise emissions (spinning phase): 75 dB(A) re 1 pW
Brand: SMEG

Electrical Connection

Nominal power: 2000 W
Current: 10 A
Voltage (V): 220-240 V
Frequency (Hz): 50 Hz
Power supply cable length: 175 cm

Logistic Information

Dimensions of the product (mm): 850x600x550
Width (mm): 600 mm
Depth (mm): 550 mm
Product Height (mm): 850 mm
Net weight (kg): 85.000 kg
Gross weight (kg): 86.000 kg
Packed width: 650 mm
Packaged depth: 655 mm
Height (mm) packed: 895 mm
Dimensions of the packed product (mm): 895X650X655
Maximum stackability: 5
Type of packaging: Shrinkwrap
Packaging composition - paper & cardboard (kg): 0.000 kg
Packaging composition - polystyrene (kg): 1.199 kg
Packaging composition - wood (kg): 0.000 kg
Packaging composition - plastic (kg): 0.395 kg
