Sous-vide Drawer Linea Aesthetic CPV115G

Vacuum drawer, 15 cm
  • Effortlessly open and close the drawer with a simple push mechanism
  • The combined use of the steam oven, blast chiller and vacuum drawer allows the preservation of product characteristics and maximum flavour enhancement
  • 3 preservation cycles (delicate, preservation, sous vide)
  • 3 vacuum levels (delicate, medium, strong)
  • Master impeccable marinades and infusions with the Chef Mode

You might also be interested in:

5 Year extended warranty

This appliance qualifies for a comprehensive Smeg 5-year warranty assistance package covering all parts and labour. Buy with confidence and added peace of mind

This offer is available on purchases made before 31st December 2024. To find out more and to redeem upon purchase, please click below.

  • Highlights
  • Features
  • Accessories
  • Download

Food Preservation

Vacuum drawers are excellent for preserving foods for longer and enhances the protection when freezing and cooking food. It is also perfect for preparing food ready for delicate sous vide cooking. Whilst many devices achieve a vacuum of 60 – 70%, the Smeg vacuum drawer can deliver 99.9%. This precision inevitably enhances the final results.

LONGER STORAGE LIFE
Foods last, on average, four times longer at room temperature or in the fridge. If frozen, food can be kept for months and retains all flavours and consistency, as if it has just been prepared. The vacuum process protects the food items from dust and bacteria. Even liquid can be vacuum sealed.

FRESH TASTING FOOD
The sealed environment preserves the nutrients and flavours to ensure that the food tastes as good as if it was made from fresh ingredients.

Key Features

CHEF FUNCTION
By compression and decompression, the Chef’s function speeds up the infusion of marinades providing excellent flavour in foods.

SOUS VIDE
Combined with special vacuum bags, and the use of Smeg’s steam oven, low temperature sous vide cooking allows you to retain aromas, juices, nutrients of the ingredients, together with consistency and flavour that is impossible to achieve through traditional cooking methods.

3 LEVELS OF VACUUM
With 1 – 3 levels of seal, you can preserve foods from mousse, soft cheese to berries, right up to meats, root vegetables and sous vide cooking.

3 LEVELS OF SEALING
It’s possible to select of 3 levels of sealing. From an open packet of crisps, to tough aluminium and multiple bags in one seal.

DOUBLE SEALING
To ensure a perfect and reliable seal, the Smeg vacuum drawer seals twice.

Accessories Available

Smeg offers a range of accessories for the vacuum drawer to be used according to the amount and the consistency of the food:

  • Vacuum seal bags with a blue label for freezer or refrigerator storage
  • Vacuum seal bags with a red label for refrigerator storage and sous-vide cooking
  • Vacuum seal containers

A number of bags for food conservation and sous vide cooking are included as standard with your vacuum drawer.

Find out more

Type

Product Family: Drawer
Type: Sous-vide
Commercial height: 14 cm
Vitality system: Yes
a: 8017709326579

Aesthetics

Colour: Neptune Grey
Finishing: Neptune Grey
Aesthetics: Linea
Material: Glass

Programs / Functions

The vacuum in container function guarantees to create vacuum into glass or plastic containers choosing among three different levels. Use only certificate containers suitable for vacuum and able to resist to a 99,9% vacuum. The vacuum in bag function guarantees to create vacuum into bags choosing among three levels. It is also possible to set the 0 level to seal the bag without creating the vacuum. The Chef function alternates compression and decompression cycles and speeds up some operations, such as marinade or infusion, that otherwise would require a lot of time. The machine can be set at three different sealing levels. Setting the maximum level is possible to seal more bags at the same time with a unique cycle.
Vacuum in container cycle: Yes, 3 levels (delicate, medium, strong)
Preservation cycle: Yes, 3 levels (delicate, preservation, sous vide)
Chef function: Yes, marinade and infusion
Welding: Yes, 3 levels (delicate, medium, strong, depending on the kind of bag used)

Controls

Type of control setting: Touch control

Technical Features

Preservation vacuum bags. These bags endure temperatures from -25°C to 70°C (for 2 hours) or 100°C (for 15 minutes). Suitable for pantry, refrigerator and freezer storage, they cannot be used for vacuum cooking. Sous-vide cooking bags. These bags endure a maximum temperature of 85°C (for 75 hours), 100°C (for 4 hours) or 121°C (for 30 minutes). Suitable for pantry and refrigerator storage, they cannot be storage in the freezer. The stabilization device maintains the drawer open when used, avoiding closing it accidentally. The vacuum sensor guarantees the achievement of the maximum vacuum connected to the level set. If the value is not reached, the bag is not sealed. The machine carries out a double phase welding which guarantees to seal dirty and oily bags as well. Setting the highest vacuum in bag/container level, it is reached a 99,9% vacuum.
Capacity: 6,5 l
Opening mechanism: Push-pull
Base material: Stainless steel 304
Lid material: Tempered glass with frame
Lid opening: 65° +/- 3°
Drawer stabilisation device: Yes
Drawer maximum protrusion: 453 +/- 2 mm
Max weight allowance: 15 kg
Maximum drawer loading weight: 48 kg
Pump flow: 4 m³/h
Safety solenoid valve anti oil reflux: Yes
Dehumidification pump cycle: Yes, automatic
Enabling vacuum bar lenght: 260 mm
Removable enabling vacuum bar: Yes
Welding type: Double-phase
Preservation cycle duration: 1' - 1'20''
Reachable vacuum: 2-10 millibar (99,9%)
Vacuum sensor: Yes, accuracy 10 mbar
Accessories included: Bags for food conservation, Bags for sous-vide cooking

Electrical Connection

Nominal power: 240 W
Current: 1 A
Voltage (V): 220-240 V
Frequency (Hz): 50-60 Hz

Logistic Information

Width (mm): 597 mm
Depth (mm): 570 mm
Net weight (kg): 29.000 kg
Gross weight (kg): 32.000 kg
Product Height (mm): 135 mm
Dimensions of the product (mm): 135x597x570
Packed width: 700 mm
Packaged depth: 700 mm
Product Height (mm) packed: 230 mm
Dimensions of the packed product (mm): 230X700X700
Maximum stackability: 8
Type of packaging: Cardboard
Packaging composition - paper & cardboard (kg): 2.217 kg
Packaging composition - polystyrene (kg): 0.788 kg
Packaging composition - wood (kg): 0.000 kg
Packaging composition - plastic (kg): 0.048 kg
