Inspired by Smeg’s very first ‘Elisabeth’ cooker produced in 1948, the Victoria range perfectly captures the essence of timeless classic design and exclusive aesthetics, thanks to Smeg’s signature 1950’s style branding and premium build quality.
Product Family
Cooker
Cooker size
60x60 cm
Aesthetics
Victoria
Colour
Cream
Hob type
Gas
Main oven type
Thermo-ventilated
Type of second oven
Static
Energy efficiency class
A
Energy efficiency class, second cavity
A
As opposed to traditional range cookers measuring between 90cm to 110cm, the TR62 allows anyone with a smaller kitchen the option to achieve the conventional aesthetic of a range cooker in compact form. It is the ideal option for kitchens where space is at a premium; compact, city-style kitchens and loft-style apartments, for example.
Despite its compact design, the TR62 still offers the very best in cooking technology. With a large double oven, it offers a 61L main oven capacity – enough to bake 60 cupcakes in one go as well as a 35 litre grill compartment.
CLOSED DOOR GRILLING
Closed door grilling allows you to grill with the door closed, keeping cooking smells inside the oven and out of the kitchen to ensure a safe cooking environment and reduced energy consumption.
Type
Product Family:
Cooker
Cooker size:
60x60 cm
Hob energy type:
Gas
N. of ovens:
2
Hob type:
Gas
Main oven type:
Thermo-ventilated
Type of second oven:
Static
EAN code:
8017709210632
Aesthetics
Colour:
Cream
Aesthetics:
Victoria
Design:
Victoria
Material:
Stainless steel
Door:
With frame
Command panel finish:
Enamelled metal
Hob colour:
Black enamel
Handle:
Smeg Victoria
Controls colour:
Stainless steel
Upstand:
Yes
Display:
electronic 5 buttons
Type of pan stands:
Cast Iron
Glass type:
Black
Handle Colour:
Brushed stainless steel
Control knobs:
Smeg Victoria
No. of controls:
6
Plinth:
Anthracite
Programs / Functions
Traditional cooking functions
-
Static
-
Small grill
-
Large grill
-
Base
Options Main Oven
Timer:
Yes
End of cooking acoustic alarm:
Yes
Minimum Temperature:
50 °C
Maximum temperature:
245 °C
Options Auxiliary Oven
Minimum Temperature:
50 °C
Maximum temperature:
245 °C
Hob technical features
Total no. of cook zones:
4
1st zone position:
Front left
2nd zone position:
Rear left
3rd zone position:
Rear right
4th zone position:
Front right
1st zone type:
Gas - 2UR (dual)
2nd zone type:
Gas - Semi Rapid
3rd zone type:
Gas - Semi Rapid
4th zone type:
Gas - AUX
1st zone power:
4.20 kW
2nd zone power:
1.80 kW
3rd zone power:
1.80 kW
4th zone power:
1.00 kW
Type of gas burners:
Standard
Burner caps:
Matt black enamelled
Automatic electronic ignition:
Yes
Gas safety valves:
Yes
Main Oven Technical Features
Net volume of the cavity:
61 litres
Gross volume, 1st cavity:
70 l
Cavity material:
Easy clean enamel
Shelf positions:
4
Type of shelves:
Metal racks
No. of lights:
1
Light type:
Halogen
Light power:
40 W
Cooking time setting:
Start and Stop
Removable door:
Yes
Full glass inner door:
Yes
Removable inner door:
Yes
Total no. of door glasses:
2
No.of thermo-reflective door glasses:
1
Safety Thermostat:
Yes
Cooling system:
Tangential
Circular heating element - Power:
2700 W
Temperature control:
Electro-mechanical
Second Oven Technical Features
Net volume of the second cavity:
35 litres
Cavity material:
Easy clean enamel
Shelf positions:
2
Type of shelves:
Metal racks
No. of lights:
1
Light type:
Halogen
Light power:
40 W
Removable door:
Yes
Full glass inner door:
Yes
Removable inner door:
Yes
No. total door glasses:
2
No. thermo-reflective door glasses:
1
Safety Thermostat:
Yes
Cooling system:
Tangential
Grill type:
Electric
Tilting grill:
Yes
Grill element - power:
1700 W
Large grill - Power:
2700 W
Lower heating element - power:
1200 W
Upper heating element - Power:
1000 W
Temperature control:
Electro-mechanical
Performance / Energy Label
Energy efficiency class:
A
GAS - Energy consumption in fan-forced convection, first cavity:
2.77 MJ
Energy consumption forced air convection (kWh) first cavity:
0.77 KWh
Performance /Energy Label - Second Cavity
Energy efficiency class, second cavity:
A
GAS - Energy consumption in conventional mode, second cavity:
2.66 MJ
GAS - Energy consumption in conventional mode, second cavity:
0.74 KWh
Electrical Connection
Nominal power:
5500 W
Voltage:
220-240 V
Voltage 2 (V):
380-415 V
Frequency:
50/60 Hz
Type of electric cable:
Yes, Double and Three Phase
Power supply cable length:
120 cm
Type of electric cable installed:
Yes, Single phase
Gas Connection
Gas connection rating (W):
8600 W
Gas Type:
G20 Natural gas
Logistic Information
Dimensions of the product HxWxD (mm):
900x600x600 mm
Width (mm):
600 mm
Product Height (mm):
900 mm
Depth (mm):
600 mm
Dimensions of the packed product (mm):
1020X670X680 mm
Gross weight (kg):
80.500 kg
Net weight (kg):
71.000 kg
FR Extention single group
Packed width:
670 mm
Packaged depth:
680 mm
Height (mm) packed:
1020 mm
Maximum stackability:
4
Type of packaging:
Cardboard
Packaging composition - paper & cardboard (kg):
4.828 kg
Packaging composition - polystyrene (kg):
2.370 kg
Packaging composition - wood (kg):
1.800 kg
Packaging composition - plastic (kg):
0.509 kg
Accessories Included
Other gas nozzles included:
G30 LPG liquid gas
Accessories included for Main Oven & Hob
Wok stand:
1
Moka stand:
1
Rack with back and side stop:
2
Grill mesh:
1
40mm deep tray:
1
Telescopic Guide rails, partial Extraction:
1
Accessories included for Secondary Oven
Rack with back and side stop:
1
Grill mesh:
1
40mm deep tray:
1
